GIGABYTE – R133-C13-AAB1
Rack Server – AMD EPYC™ 4005/4004 & Ryzen™ 9000/7000 – 1U UP 1 x PCIe Gen5 GPU Platinum
Key Features
- Supports 1 x Dual slot Gen5 GPU
- Single AMD EPYC™ 4005/4004 & Ryzen™ 9000/7000 Series Processors
- Dual Channel DDR5 ECC/Non-ECC UDIMM, 4 x DIMMs
- 2 x 1Gb/s LAN ports via Broadcom® BCM5720
- 4 x 3.5″/2.5″ SATA hot-swap bays
- 1 x M.2 slot with PCIe Gen4 x4 interface
- 1 x FHFL PCIe Gen5 x16 slot for GPUs
- 1 x FHHL PCIe Gen4 x4 slot
- 1+1 800W 80 PLUS Platinum redundant power supplies
| Weight | 20.2 kg |
|---|---|
| Dimensions | 98.2 × 59.4 × 25 cm |
Description
■ Rack Server – AMD EPYC™ 4005/4004 & Ryzen™ 9000/7000 – 1U UP 1 x PCIe Gen5 GPU Platinum
► Specifications
| Specification | Details |
|---|---|
| Dimensions (WxHxD) | 1U 438 x 43.5 x 710 mm |
| Motherboard | MC13-BL1 |
| CPU | AMD EPYC™ 4005 Series Processors AMD EPYC™ 4004 Series Processors AMD Ryzen™ 9000 Series Processors AMD Ryzen™ 7000 Series Processors Single processor TDP up to 170W Overclocking is not supported due to thermal limitations. |
| Socket | 1 x AM5 |
| Chipset | AMD B650E |
| Memory | 4 x DIMM slots DDR5 memory supported Dual Channel memory per processor ECC / Non-ECC memory supportedAMD EPYC™ 4005 / Ryzen™ 9000: UDIMM: Up to 5600 MT/s (1DPC) UDIMM: Up to 3600 MT/s (2DPC)AMD EPYC™ 4004 / Ryzen™ 7000: UDIMM: Up to 5200 MT/s (1DPC) UDIMM: Up to 3600 MT/s (2DPC) |
| LAN | Rear: 2 x 1Gb/s LAN (Broadcom® BCM5720) Support NCSI function 1 x 10/100/1000 Mbps Management LAN |
| Video | Integrated in ASPEED® AST2600 1 x Mini-DP |
| Storage | Front hot-swap: 4 x 3.5″/2.5″ SATA Internal M.2: 1 x M.2 (2280/22110) PCIe Gen4 x4 interface SATA supported only |
| SAS | N/A |
| RAID | RAID 0 / 1 / 10 Optional RAID add-in card support |
| PCIe Expansion Slots | PCIe Cable: 1 x FHFL x16 (PCIe Gen5 x16) from CPU for GPU Riser Card CRSE016: 1 x FHHL x4 (PCIe Gen4 x4) from CPU Supports GPUs up to 300W |
| Front I/O | 2 x USB 3.2 Gen1 ports (Type-A) 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED |
| Rear I/O | 2 x USB 3.2 Gen1 ports (Type-A) 1 x Mini-DP 2 x RJ45 ports 1 x MLAN port 1 x ID button with LED |
| Backplane Board | SATA 6Gb/s |
| Security Modules | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 |
| Power Supply | 1+1 800W 80 PLUS Platinum redundant power supplies AC Input: 100-240V~ / 10-5A / 50-60Hz DC Input (China only): 240Vdc / 4A DC Output: Max 800W +12V / 65A +12Vsb / 2.1A |
| System Management | ASPEED® AST2600 Baseboard Management Controller GIGABYTE Management Console web interface Dashboard HTML5 KVM Sensor Monitor Sensor Reading History Data FRU Information SEL Log Hardware Inventory Fan Profile System Firewall Power Consumption Power Control Advanced Power Capping LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings |
| OS Compatibility | EPYC 4005 / 4004: Ubuntu 22.04 Ubuntu 24.04 Windows Server 2022 Windows Server 2025 Ryzen 9000 / 7000: Windows 10 21H2 Windows 11 |
| System Fans | 5 x 40x40x56mm |
| Operating Properties | Operating temperature: 10°C to 30°C Operating humidity: 8% to 80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20% to 95% (non-condensing) |
| Weight | Net Weight: 17.82 kg Gross Weight: 20.2 kg |
| Packaging Dimensions | 982 x 594 x 250 mm |
| Packaging Content | 1 x R133-C13-AAB1 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 1 x GPU power cable (2x PCIe 8pin, 700mm) 1 x 2-Section Rail kit |
| Part Numbers | Barebone package (EPYC 4005/Ryzen 9000): 6NR133C13MR000ACB1* Barebone package (EPYC 4004/Ryzen 7000): 6NR133C13MR000ABB1* Barebone package (Ryzen 7000): 6NR133C13MR000AAB1* Motherboard: 9MC13BL1NR-000* 2-Section Rail kit: 25HB2-3A0203-K0R CPU heatsink: 25ST1-443301-S7R M.2 heatsink: 12SP2-11000E-00R Front panel board – CFP1010: 9CFP1010NR-00* Backplane board – CBP1047: 9CBP1047NR-00* Fan module: 25ST2-405623-A0R Fan module: 25ST2-40562H-A0R Riser card – CRSE016: 9CRSE016NR-00* Mini-DP to D-Sub cable: 25CRN-200801-K1R GPU power cable: 25CRI-700004-G5R Power supply: 25EP0-208009-F3S |
TECHNICAL RESOURCES
-
Manual : Datasheet (English)
